KMT STREAMLINE® SL-VI 60,000 PSI PUMPS 100HP
Description & Details
Specification: Streamline® Series VI 100 HP dual-intensifier / redundant-intensifier standard-edition ultra-high-pressure waterjet pump
-
Brand: KMT (Cobrem / KMT)
Series: Streamline®
Model: SL-VI 100R
Technical Specifications
Intensifier: Dual intensifier
Pressure Range: 500 – 4137 bar
Maximum Flow Rate at Rated Pressure: 7.12 L/min
Motor Starter: 100 HP / 75 kW, 380V / 50/60Hz motor starter
Hydraulic Reservoir Capacity: 55.8 gal / 211 L
Rated Current (Full Load): 124 A
Accumulator: 2 L maintenance-free accumulator for stable operating pressure
Weight: 2284 kg
Dimensions (L×W×H): 2095 × 1316 × 1462 mm
Intensifier: Electronically monitored reversing intensifier
Seals & Plunger: Metal-end seal intensifier seals with ceramic plunger
Hydraulic Pump: Variable-flow, pressure-compensated hydraulic pump
Automatic Shutdown: PLC-programmable automatic shutdown sensors (triggers on high hydraulic oil temperature, low inlet water pressure, etc.)
Safety Relief Valve: Built-in automatic high-pressure relief valve for safe pressure bleed-off during system shutdown or emergency stop
Water Filtration: Water booster and filtration system
Design: Protective shrouds with frame structure for easy maintenance and service access
