Inverted / Side-Mounted Fixed-Table Series
-
Inverted or Side-Mounted Fixed-Table Robotic Waterjet Cutting Workstation
1) Inverted or side-mounted configuration for 1–4 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1–2 persons.
4) Applicable products: Designed for inline/FLOW production lines; suitable for high-volume production with low product variety.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Mold/fixture lifter or quick mold-change cart: Reduces mold/die changeover time. -
Integrated Inverted or Side-Mounted Fixed-Table Robotic Waterjet Cutting Cell
1) Inverted or side-mounted configuration for 1–4 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1–2 persons
4) Applicable products: Designed for inline/FLOW production lines; suitable for high-volume production with low product variety.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Mold/fixture lifter or quick mold-change cart: Reduces mold/die changeover time. -
Split-type Inverted or Side-Mounted Fixed-Table Robotic Waterjet Cutting Cell
1) Inverted or side-mounted configuration for 1–4 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1–2 persons.
4) Applicable products: Designed for inline/FLOW production lines; suitable for high-volume production with low product variety.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Mold/fixture lifter or quick mold-change cart: Reduces mold/die changeover time.
Inverted / Side-Mounted Rotary-Table Series
-
Inverted or Side-Mounted Rotary Table Open Robotic Waterjet Cutting Cell
1) Inverted or side-mounted configuration for 2–3 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1 person.
4) Applicable products: Integrated with production lines; supports both fixed-table and rotary-table cutting; suitable for multi-variety, high-volume production.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Jib crane: Assists operators with mold/die changeovers. -
Inverted Or Side-mounted Rotary Table Enclosed Robotic Waterjet Cutting Cell
1) Inverted or side-mounted configuration for 2–3 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1 person.
4) Applicable products: Integrated with production lines; supports both fixed-table and rotary-table cutting; suitable for multi-variety, high-volume production.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Jib crane: Assists operators with mold/die changeovers. -
Enclosed Robotic Waterjet Cutting Cell With Inverted Or Side‑mounted Rotary Table And Platform
1) Inverted or side-mounted configuration for 2–3 robots.
2) Robot models available: ABB (IRB 2400, IRB 1600); Yaskawa (MH24, MH12); FANUC (M-20iA).
3) Operators required: 1 person.
4) Applicable products: Integrated with production lines; supports both fixed-table and rotary-table cutting; suitable for multi-variety, high-volume production.
5) Optional configurations:
A. Steel structure platform: Houses high-pressure pumps, water softening units, and cooling water units to minimize footprint.
B. Jib crane: Assists operators with mold/die changeovers.
Slide-Table Waterjet Cutting Cell Series
-
Single-Station Sliding Table Waterjet Cutting Cell
1) Inverted or side-mounted configuration for 1–4 robots.
2) Operators required: 1–2 persons.
3) Applicable products: Suitable for single-piece or small-batch heavy workpieces requiring high-precision positioning. -
Dual‑station Waterjet Cutting Cell with Alternating Operation
1) Inverted or side-mounted configuration for 1–4 robots.
2) Operators required: 1–2 persons.
3) Applicable products: Suitable for single-piece or small-batch heavy workpieces requiring high-precision positioning. -
Dual-Station Compact Helmet Waterjet Cutting Workstation (Sliding Table Series)
1) Accommodates 1–2 robots.
2) Robot models available: ABB (IRB 1600, IRB 2600, IRB 4600); Yaskawa (GP25); FANUC (M-20iD).
3) Operators required: 1–2 persons.
4) Applicable products: Multi-variety, small-to-medium volume production
Upright Open-Frame Series
-
Robotic Waterjet Cutting Cell With Upright Robot, Open Access, And Stationary Table.
1) Accommodates 1–2 centrally mounted robots.
2) Robot models available: ABB (IRB 4600); Yaskawa (MH50-20); FANUC (M-70iA).
3) Operators required: 2 persons.
4) Applicable products: Large workpieces, workpieces with complex cavities, multi-variety, small-to-medium volume production. -
Robotic Waterjet Cutting Cell With Upright Robot, Open Access, And Rotary Table
1) Accommodates one or two robots.
2) Optional robot models: ABB 4600, ABB 2600; Yaskawa MH50II‑20, MH24; FANUC M70IA, M20IA.
3) Operated by a single operator.
4) Suitable for medium‑sized workpieces, with high‑mix, small‑to‑medium batch production. -
Robotic Waterjet Cutting Cell With Upright Robot, Open Access, Stationary Table, And Platform.
1) Accommodates one or two robots placed in the center.
2) Optional robot models: ABB 4600; Yaskawa MHII50‑20; FANUC M70IA.
3) Operated by two operators.
4) Suitable for large workpieces with complex cavities, and high‑mix, small‑to‑medium batch production.
